99 High Availability Fabric Manager User Guide
5
Using the Fabrics View
This chapter provides information to help you use the Fabrics View in the High
Availability Fabric Manager window.
Overview
Access the Fabrics View by clicking the Fabrics tab on the HAFM window. The
left panel of this view is the Fabric Tree, which is the expandable list of fabrics,
products in fabrics, and nodes connected to products. The view area for the tab is
to the right of the Fabric Tree.
Click the Topology and Zone Set tabs at the bottom of the view area to change
the views. The Topology tab (default) is illustrated in
Figure 47 .
Figure 47: Fabrics View — Topology tab
