Using the Menu Bar
65
High Availability Fabric Manager User Guide
View
The View menu displays options that alter the view of application components.
User Sessions
Choose the User Sessions option to display the User Sessions dialog box
(
). This dialog box lists all the current management sessions, including
the name of each user connection, the network address of the user, and the time
when the connection was established. Click Close when you have finished
reviewing the sessions.
Figure 26: User Sessions dialog box
Zoom
Choose the In and Out options from the Zoom option to increase and decrease the
size of fabric elements. Return to the original view by selecting the Default
option.
Choose the Fit In View option to display the entire fabric in the view area. Note
that for larger fabrics, text and icons may be difficult to see. Choose Default from
the Zoom menu to return to the original view, or use the Out option to selectively
reduce the view.
