Using the HAFM Window
53 High Availability Fabric Manager User Guide
Fit Topology in View Icon
In the Fabrics View, the Fit Topology in View icon ( Figure 23 ) is available when
the Topology tab is selected. Choose the Fit Topology in View icon to display
the entire fabric in the Topology tab view area. Note that for larger fabrics, text
and icons may be difficult to see. Return to the original size by choosing View >
Zoom Default.
Figure 23: Fit Topology in View icon
Main Panel
The HAFM main panel contains two views, which are displayed by choosing
either the Products tab or the Fabrics tab.
Products View
When you first access the HAFM, the Products View displays, as shown in
Figure 24 . To access the Products View from the Fabrics View, click the
Products tab.
