Fabric Zoning
149
High Availability Fabric Manager User Guide
Note:
Names for zones and zone sets must follow specific rules. Refer to “
Conventions for Zones and Zone Sets
” on page 139 for details.
5. Select the fabric for which zoning is being configured from the drop-down
menu.
6. In the Attached ports/nodes area, click the icon to the left of a numbered
domain folder to display a list of ports and attached nodes for the director or
switch (
). Note that the WWN for the switch or director displays to
the right of the product’s domain number.
A list of ports with attached nodes expands under the selected domain.
Figure 61: New Zone dialog box
Note:
The icon that you click to expand the list of ports may not appear by a domain
where no nodes attached to ports.
