Page 136
Fabric Zoning
136
High Availability Fabric Manager User Guide
illustrates how zones can consist of ports and/or devices installed on
ports in three managed products in a multiswitch fabric.
Figure 59: Zoning through a multiswitch fabric
Zone 1
Interswitch Link
Zone 3
Zone 2
Director
Director
Director
