Step 3 Configure CPU,
Continued
Summary of Jumper Setting for Intel Pentium CPUs
Multi
Ext.
IMI 652 Clock Generator
OCS 9147 Clock Generator
Speed
plier
Speed
CLK1
CLK2
CLK3
CLK1
CLK2
CLK3
FREQ1
FREQ
2
FRE
Q3
P55C
233
3.5x
66
200
3x
66
166
2.5x
66
P54C
200
3x
66
166
2.5x
66
150
2.5x
60
133
2x
66
120
2x
60
100
1.5x
66
90
1.5x
60
Cont’d
