Component identification 15
Item Description
23 Reserved
24
SATA connector 5 (optical drive)*
25 Internal USB option connector
26 Reserved
27
SATA connector 3 (hard drive)
28 SATA connector 1 (hard drive)
29 Parallel option connector
30 Serial option connector
31 Reserved
32
PCI Express expansion slot 4
33 PCI Express expansion slot 5**
34 Reserved
35 Reserved
36 Reserved
37
Dedicated iLO2 optional module connector
* The server supports one optical drive that can be connected to either SATA connector 5 or SATA connector 6.
**x8 PCI Express cards are supported, but will run at x1 speeds.
System maintenance switch
Position Default Function
S1 Off Off = iLO 2 security is enabled
On = iLO 2 security is disabled
S2 Off Off = Normal operation
On = RBSU will not commit any
configuration changes*
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password enabled
On = Power-on password disabled*
S6 Off Off = Normal operation
On = BIOS will clear CMOS and
NVRAM*
S7 Off Reserved
S8 Off Reserved
* "On" activates the function.
