Introduction
27 Embedded Web Server User Guide
Starting EWS
Open the EWS interface as follows:
1. Ensure the workstation (or device you use to launch the web browser) and the
Ethernet LAN segment containing the product, such as Edge Switch 2/24, are
attached and connected through the Internet.
Note: You must be able to make a connection between the web browser and the
product in order to log in to the product.
2. Launch the web browser application (such as Netscape Navigator, version 4.6
or higher, or Microsoft Internet Explorer, version 4.0 or higher).
3. At the web browser, enter the IP address of the product as the Internet uniform
resource locator (URL) such as http://10.1.1.11.
Note: If the product has not been installed, refer to the product’s installation and
service manual for the appropriate IP address, login ID, and password that is initially
used when you install and configure the product.
After a connection is made between the web browser and the product, the
logon dialog box displays as shown in
Figure 2 .
Figure 2: Logon dialog box
4. Type the user name and password. The EWS interface opens with the View
page displayed, as shown in Figure 3 .
