Viewing Product and Fabric Data
112 Embedded Web Server User Guide
Note: If the message
Attempting to Collect Data
displays in a product cell,
you may want to reload the page, because it will not update automatically after the
initial view is loaded.
Parts of the Product Cell
The product cell has the following parts:
■ A graphic representation of the device and its status. For more information,
see “
Parts of the Product Graphic ” on page 113.
■ Information about the device. For more information, see “ Product Cell
Information ” on page 112
■ View Topology text that acts as a hyperlink to the Topology page for the
fabric (firmware 04.00.00 and higher only). Choose this hyperlink to view the
Topology page. (The hyperlink is found only on the Edge Switch 2/16, Edge
Switch 2/32, Edge Switch 2/24, SAN Director 64, Director fc-64,
Director 2/64, and Director 2/140.) Other HP switches and non-HP products
do not have this hyperlink.
Product Cell Information
Each product cell provides information about a device on the fabric as described
in
Table 6 .
Table 6: Information on the Product Cell
Information Description Availability
Domain ID Domain ID of the product
used in the fabric.
Available for any product.
WWN WWN of the product used in
the fabric.
Available for any product.
IP IP addresses of the product. HP high availability fabric
directors and switches only.
