Viewing Port Properties
To view the properties of a port on a product, perform the following procedure:
1. Choose View from the navigation panel.
2. Choose the Port Properties tab. The Port Properties tab view displays
( Figure 27 ) showing the properties for only one port.
Table 5: Status Indicators
View LED Name Color Behavior
Front System Power Green Off when the LAN is down.
On when the LAN is up.
System Error
Light (SEL)
Amber Off when the SEL on the
hardware is off.
On when the SEL on the
hardware is on.
When this
indicator illuminates, an
event has occurred requiring
immediate attention, such as
a system, fan, power supply,
or port failure.
Port Online Green/Blue Off when port status is
anything but Online.
Green when port status is
Online and the operating
speed is 1 Gb/s.
Blue when port status is
Online and the operating
speed is 2 Gb/s (Edge
Switch 2/24 only).
Port Service
Required
Amber Off when port status is
anything but Failed or Service
Required.
On when port status is Failed
or Service Required.
Rear FRU Service
Required
Amber Off when FRU status is Active.
On when FRU status is Failed.
