Viewing Product and Fabric Data
101 Embedded Web Server User Guide
■ Name — The user-defined name or description assigned to the product.
■ Front View and Rear View — Using this graphical view of the product, you
can view status symbols and simulated light emitting diode (LED) indicators,
display data, or use mouse functions to monitor status and obtain vital product
information for the product and its hardware components.
Move the cursor over parts of the graphics to display labels identifying each
hardware component or port and its slot position in the chassis. Choose a port
to view the corresponding Port Properties tab for the port. Choose an FRU to
view the FRU Properties tab for the FRU.
Colored indicators reflect the status of actual LEDs on the product’s
components.
Table 5 describes the port operational states and the LED and
attention indicators that display on the Switch or Director page.
Table 4: State Definitions
State Description
OFFLINE When the product is OFFLINE, all ports are offline. The
ports cannot accept a login from an attached device and
cannot connect to other switches. You can configure this
state through the Online State tab view (See “ Setting
Product Online or Offline ” on page 137 for instructions).
Online All unblocked ports are able to connect with devices.
You can configure this state through the Set Online State
tab view (See “ Setting Product Online or Offline ” on
page 137 for instructions). Note that the product
automatically goes online after a power-up, an initial
machine load (IML), or initial program load (IPL).
