Using the cable tab (1), carefully lift up and disconnect the hard drive cable from the computer,
and then pull the cable out from the routing clips (2).

Using a small Phillips screwdriver, remove the 2 hard drive mounting screws (1), and
corresponding screw mounting hardware (2). Using the tab (3), lift and remove the hard drive
assembly from the bay.

NOTE:

After removing the hard drive from the computer, you must remove the hard drive

bracket to access the hard drive itself.

Spread the soft-molded hard drive bracket (1) and remove the hard drive (2).
