HP OmniBook 800 Notebook PC - Manual (Page 12)

1-12
To insert a CD into the CD-ROM drive
1. Press OPEN to open the disk cover.
2. Place a CD (with the label facing up) on the center spindle, and press down
firmly on the center of the CD until it seats on the spindle.
3. Close the disk cover.
The following messages appear on the display readout.
Message/Indication Description
-AUDIO DISC ONLY- Displayed when you press an audio control button while a data CD is in
the CD-ROM drive.
BATTERY Displayed to indicate low battery power.
BUSY Displayed when CD-ROM drive is transferring data to the OmniBook.
no dISC Displayed when there is no disk in the CD-ROM drive.
on Displayed if a data CD is present. During inspection of a new disk (data or
audio), the “on” message blinks.
OPEN Displayed when the disk cover is open.
Disk Cover
Center Spindle
CD
