Component Description
● Amber (left): Activity is occurring on the
network.
(5) HDMI port Connects an optional video or audio device, such as
a high-definition television, any compatible digital or
audio component, or a high-speed HDMI device.
(6) USB 3.0 ports (2) Each USB 3.0 port connects an optional USB
device, such as a keyboard, mouse, external drive,
printer, scanner or USB hub.
(7) Memory card reader Reads optional memory cards that store, manage,
share, or access information.
To insert a card:
Hold the card label-side up, with connectors facing
the slot, insert the card into the slot, and then push
in on the card until it is firmly seated.
To remove a card:
Press in on the card it until it pops out.
(8) Speakers (2) Produce sound.
(9) Volume button Controls speaker volume.
● To increase speaker volume, press the + edge
of the button.
● To decrease speaker volume, press the – edge
of the button.
(10) Audio-out (headphone)/Audio-in
(microphone) jack
Connects optional powered stereo speakers,
headphones, earbuds, a headset, or a television
audio cable. Also connects an optional headset
microphone. This jack does not support optional
microphone-only devices.
WARNING! To reduce the risk of personal injury,
adjust the volume before putting on headphones,
earbuds, or a headset. For additional safety
information, refer to the Regulatory, Safety, and
Environmental Notices . To access this guide, from
the Start screen, type support, and then select the
HP Support Assistant app.
NOTE: When a device is connected to the jack,
the computer speakers are disabled.
NOTE: Be sure that the device cable has a 4-
conductor connector that supports both audio-out
(headphone) and audio-in (microphone).
(11) USB 2.0 port Connects an optional USB device, such as a
keyboard, mouse, external drive, printer, scanner or
USB hub.
Multimedia features 23
