Setting Up the Application
77 HA-Fabric Manager User Guide
6. Enter the UDP port number in the Port field. This overrides the default User
Datagram Protocol (UDP) port number for a trap recipient with any legal,
decimal UDP number.
7. Choose a community string from the Community String drop-down list.
8. Click OK.
Editing Trap Recipients
To edit an existing trap recipient during SNMP agent configuration, use the
following steps:
1. Choose Monitor > SNMP Agent > Setup. The SNMP Agent Setup dialog
box displays, as shown in Figure 28 on page 75.
2. Click the Trap Recipients tab.
3. Click to highlight the IP address in the Trap Recipients table to edit.
4. Click Edit. The Edit Trap Recipient dialog box displays, as shown in
Figure 30 .
Figure 30: Edit Trap Recipient dialog box
5. Edit the fields as necessary.
6. Click OK.
Removing Trap Recipients
To remove an existing trap recipient during SNMP agent configuration, use the
following steps:
Note: This procedure removes trap recipients without asking for confirmation.
1. Choose Monitor > SNMP Agent > Setup. The SNMP Agent Setup dialog
box displays, as shown in Figure 28 on page 75.
