Setting Up the Application
48 HA-Fabric Manager User Guide
Accessing HAFM on the HAFM Appliance
You can log in to HAFM located on the appliance from a browser-capable PC
connected through an Ethernet LAN segment. Use the following steps:
1. Ensure the HAFM appliance and a browser-capable PC are connected through
an Ethernet LAN segment. At the PC, launch the browser application
(Netscape Navigator
or Internet Explorer).
2. At the PC browser, enter the URL in the following format:
http://xxx.xxx.xxx.xxx:5800
Where xxx.xxx.xxx.xxx is the default IP address or the IP address
configured for the appliance during installation. The VNC Authentication
window displays, as shown in
Figure 12 .
Figure 12: VNC Authentication window
3. Type the password and click OK. The Welcome to Windows dialog box
displays, as shown in Figure 13 .
Note: The default TightVNC viewer password is password.
Figure 13: Welcome to Windows dialog box
