Reference
272 HA-Fabric Manager User Guide
Product Status Icons
Event Icons
Band Information Status Icons
Planned Device Icons
Icons of planned devices illustrate the device being unpacked from a box.
Table 26 illustrates the planned icons for various devices.
Table 23: Product Status Icons
Icon Status
No icon Operational
Degraded
Failed
Unknown/Offline
Table 24: Event Icons
Icon Description
Informational
Warning
Fatal
Table 25: Band Information Status Icons
Icon Out-of-Band In-Band Icon Out-of-Band In-Band
Present Not Present Present Present
Failed Not Present Present Failed
Not Present Present Failed Present
Not Present Failed Failed Failed
