Reference
273 HA-Fabric Manager User Guide
Group Icons
Connections
Figure 114: Online connection with online devices
Table 26: Planned Device Icons
Icon Description Icon Description
Planned Host Bus Adapter
(HBA)
Planned Network Attached
Storage (NAS)
Planned Switch Planned Storage
Planned Hub Planned Tape
Planned Bridge Planned Unknown Device
Planned JBOD Planned appliance
Table 27: Group Icons
Icon Description Icon Description
Host Isolated Group
Switch Bridge
Loop Fabric
