Configuring Zoning
190 HA-Fabric Manager User Guide
Zoning Limitations
HAFM has the ability to configure large zone sets, including up to 1024 zones and
1024 end ports in a single zone set.
Table 14 shows the supported limits for the
edge switches and directors.
Note: Hard Zoning is enforced upon firmware initialization. Devices not conforming
to zoning rules are restricted to their assigned zones.
Table 14: Zoning Parameters Supported Limits
Note: The supported number of zones is based on a zone name with a maximum of
32 characters. On all edge switches and directors except the Director 2/140, the
maximum number of zones decreases if full 64 character names are used. The
supported limits are based on two members per zone.
Zoning Parameter Maximum Value
Number of zone members in a zone 2048
Number of zones in zone set 1024
number of unique zone members in a
zone set
2048
Total number of zone members in a
zone set (where a zone member can be
in multiple zones)
4096
Characters per zoning name 32
Number of unique zone members in
HAFM Zoning Library
2048
Number of zones in HAFM Zoning
Library 1024
Number of zone sets in HAFM
Zoning Library 64
Number of end ports 1024
Number of devices supported
(including loop devices) 1024
