HP StorageWorks 2.32 Edge Switch - Manual (Page 166)

Optional Features
166 HA-Fabric Manager User Guide
Open Trunking Log
The Open Trunking log as shown in Figure 87 , provides details on flow rerouting
that is occurring through switch ports.
Figure 87: Open Trunking log
■ Date and Time—Date and time that action occurred.
■ Receive Port—The decimal receive port number on the local switch
associated with the flow that was rerouted.
■ Target Domain—The decimal domain ID associated with the flow that was
rerouted.
■ Old Exit Port—The decimal exit port number on this switch that the flow
used to get to the target domain.
■ New Exit Port—The decimal exit port number on this switch that the flow
now uses to get to the target domain.
