HP StorageWorks 2.32 Edge Switch - Manual (Page 123)

Monitoring SAN Products
123 HA-Fabric Manager User Guide
Figure 66: Select Template Dialog Box
Note: You can also generate a report of the Physical Map by clicking the Generate
Reports button (or CTRL+G) on the right-hand toolbox while viewing a discovered
SAN.
2. Select the type(s) of reports you want to generate.
3. Click OK.
4. The generated reports will automatically display in the HAFM 8 Reports
dialog box.
5. To print the report, click Show in Browser to display the selected report in
your default Web browser.
6. Choose File > Print in the Web browser.
Note: Hyperlinks in reports are only active as long as the source data is available.
Viewing and Printing Reports
You can view reports through the application, or through an internet browser.
Reports are stored in
\Server\Reports\ .
From the Monitor menu, select Report, then View. The HAFM Reports dialog
box displays as shown in
Figure 67 .
