4 Using HP 3PAR HE Deployment Tool GUI
Open HP 3PAR HE Deployment tool by double-clicking the shortcut icon on the desktop, or by
selecting Start Menu All Programs Hewlett-Packard HP 3PAR Host Explorer HP 3PAR Host
Explorer Deployment Tool.
NOTE: If the GUI does not launch when opened from the desktop shortcut, then the user has to
launch the GUI from the command line to troubleshoot as specified in this “section” (page 7) .
The HP 3PAR HE Deployment tool page is displayed, as shown in Figure 1 (page 9) .
After opening the GUI, the user can view the following options in the left navigation:
•
Host Configuration
•
Deploy Host Explorer
•
Historical Reports
•
Settings
Figure 1 HP 3PAR HE Deployment tool options
Host configuration
The Host Configuration option appears as shown in Figure 2 (page 10) .
Host Configuration option lists the host credentials that are currently configured. The fields shown
are as follows:
•
Host IP – This displays the IP address of the configured OS type.
•
Username – This displays the User name associated with the IP address.
•
OS type – This displays the type of the operating system.
•
Domain – This displays the domain associated with the IP address (applicable only for Windows
OS).
Host configuration 9
