HA-Fabric Manager user guide 91
Configuring the SNMP agent
This section provides information to help you use the SNMP agent module.
Setting up the SNMP agent
The SNMP agent module implements the objects defined in the Fibre Channel Management
(FCMGMT) Management Information Base (MIB) 3.1 and a small number of objects defined in MIB
II. Through implementation of these MIB objects, the agent translates information stored on the
appliance into a form usable by SNMP management stations.
You can configure network addresses and community names for up to 12 SNMP trap recipients.
SNMP sends messages for specific events that occur on the appliance to trap recipients.
Figure 45 shows the dialog box used to configure the SNMP agent.
Figure 45 SNMP Agent Setup dialog box
Turning the SNMP agent on or off
To turn the SNMP agent on or off, select Monitor > SNMP Agent > On | Off.
Configuring trap recipients
To configure the SNMP agent that runs on the appliance and implements the Fibre Alliance MIB:
1. Select Monitor > SNMP Agent > Setup.
The SNMP Agent Setup dialog box is displayed (
Figure 45 ).
2. Click the Trap Recipients tab.
3. Select Enable Authorization Traps if you want to enable messages to be sent when unauthorized
management stations try to access SNMP information through the appliance.
4. Click Add.
