HA-Fabric Manager user guide 87
NOTE: All IP addresses in a sequence must be on the same subnet and have the same first three
octets.
6. Click OK.
Changing an IP address
To edit IP addresses or associated subnets that are listed on the Discover Setup dialog box:
1. Select Discover > Setup.
The Discover Setup dialog box is displayed (
Figure 39 on page 82).
2. Select the IP address you want to change from the Available Addresses list.
3. Click Edit.
The Address Properties dialog box is displayed (
Figure 42 on page 86).
4. Edit the information as necessary.
5. Click OK.
6. Click OK.
Removing an IP address
CAUTION: This procedure removes the IP addresses without prompting you for a confirmation.
To remove IP addresses from the Discover Setup dialog box:
1. Select Discover > Setup.
The Discover Setup dialog box is displayed (
Figure 39 on page 82).
2. Select the IP address that you want to remove from the Available Addresses list.
3. Click Remove.
4. Click OK.
Configuring a community string
The community string defines read/write accessibility to devices. By default, the public community
has read-only privileges, and the private community has read/write privileges. However, you can
customize the community string. To specify community strings used to communicate with products,
perform the following procedure:
1. Select Discover > Setup.
The Discover Setup dialog box is displayed (
Figure 39 on page 82).
2. Select the IP address that you want to change from the Available Addresses list.
3. Click Add.
The Address Properties dialog box is displayed (
Figure 42 on page 86).
4. Click the SNMP tab.
