HA-Fabric Manager user guide 83
NOTE: To discover all SAN products, you must specify each product’s IP address in the Discover
Setup dialog box (Out-of-Band tab). If you do not configure the application to discover the devices
directly, the connections and attached devices may not be correct on the window.
2. Select IP addresses from the Available Addresses list and add them to the Selected Individual
Addresses list by clicking the right arrow ( ) button.
3. Click OK.
4. Click Add to specify the IP addresses you want to discover through out-of-band discovery.
You can add, change, and remove IP addresses as necessary. See ”
Configuring IP addresses
and community strings ” on page 86 for instructions.
5. Select the entries from the Selected Individual Addresses list that you do not want to discover
now, and move them back to the Available Addresses list by clicking the corresponding left
arrow button.
6. Click OK.
7. Turn discovery on or off by selecting Discover > On or Discover > Off.
Troubleshooting discovery
If you encounter discovery problems, use the following procedure to ensure that discovery was set
up correctly:
1. Verify IP connectivity by pinging the switch.
a. Display the command prompt.
b. From the server, type ping switch IP address.
2. Verify the SNMP settings.
a. Launch HAFM Basic interface by opening a web browser and entering the IP address of the
product as the Internet URL.
For example, http://10.1.1.11 .
b. Log in and click OK.
c. Select Configure > SNMP.
