HA-Fabric Manager user guide 273
Band information status icons
Planned device icons
Icons of planned devices illustrate the device being unpacked from a box. Table 35 illustrates the
planned icons for various devices.
Table 34 Band information status icons
Icon Out-of-band In-band Icon Out-of-band In-band
Present Not Present Present Present
Failed Not Present Present Failed
Not Present Present Failed Present
Not Present Failed Failed Failed
Table 35 Planned device icons
Icon Description Icon Description
Planned Host Bus Adapter
(HBA)
Planned Network Attached
Storage (NAS)
Planned switch Planned storage
Planned hub Planned tape
Planned bridge Planned unknown device
Planned JBOD Planned appliance
