HA-Fabric Manager user guide 147
• Minimap
Select View > Planned SAN. The Planning window is displayed ( Figure 91 ).
Figure 91 Planning window
Plan design
By designing a plan, you can configure, connect, and arrange planned devices. This saves you cost
and time by enabling you to evaluate the plan before implementing the design.
Planning a SAN
To plan a new SAN:
1. Select SAN > New Plan (or press Ctrl-N) from the Planning window menu.
The New Plan dialog box is displayed (
Figure 92 ).
Figure 92 New Plan dialog box
2. Enter a name in the New Plan box.
