HA-Fabric Manager user guide 127
The Add Rule dialog box is displayed ( Figure 77 ).
Figure 77 Add Rule dialog box
3. Enter information in the following fields:
• Name
• Group
• Description
4. Select the Active check box to make the rule active after you are finished creating it.
5. Select the type of trigger from the Trigger list.
6. Follow the instructions on the window.
NOTE: Each selection on the Trigger list or Actions list shows a different dialog box with
instructions. Follow the instructions on each dialog box to create rules.
Managing Event Management
You can turn Event Management on or off by clicking the on or off button on the top right corner or
the Event Management tab.
