HA-Fabric Manager user guide 125
NOTE: You can specify macros for some actions by clicking in the Value column and then
right-clicking and selecting an argument from the menu. See ” Writing Event Management macros ”
on page 281 for instructions.
Window
To view Event Management, click the Event Management tab on the HAFM main window. All
configured rules display ( Figure 76 ). From this dialog box, you can manage Event Management
rules. See Table 17 for a description of each window section.
Table 17 Event Management tab
Window section Description
# column Specifies the auto-assigned rule number.
Actions list Lists the actions to be performed when the
rule’s triggers are met.
Activate button Click to activate the selected rules.
Active column Specifies whether the rule is on.
Change button Click to change the reset interval.
Copy button Click to duplicate the selected rule.
Date Modified column Lists the date and time that the rule was last
edited.
Deactivate button Click to deactivate the selected rules.
Delete button Click to delete the selected rule.
Description field Lists the description of the selected rule.
Description column Specifies the user-defined rule description.
Edit button Click to edit the selected rule.
Group column Lists the group to which the rule belongs.
Name column Specifies the user-defined rule name.
New button Click to add a new rule.
OFF button Click to turn the Event Management feature
off.
ON button Click to turn the Event Management feature
on.
Trigger list Lists the trigger for the selected rule.
User column Specifies the last user to modify the rule.
