Chapter 4 Installation
24 Avaya P332G-ML User’s Guide
Table 4.4 displays the different types of SFP GBIC interfaces, their fiber type,
diameter, modal bandwidth, wavelengths, minimum and maximum distance.
Table 4.4 Gigabit Ethernet Cabling
Gigabit
Interface Fiber
Type Diameter
(µm)
Modal
Bandwidth
(MhzKm) Maximum
Distance
(m) Minimum
Distance
(m)
Wavelength
(nm)
1000BASE-SX MM 62.5 160 220 2 850
1000BASE-SX MM 62.5 200 275 2 850
1000BASE-SX MM 50 400 500 2 850
1000BASE-SX MM 50 500 550 2 850
1000BASE-LX MM 62.5 500 550 2 1310
1000BASE-LX MM 50 400 550 2 1310
1000BASE-LX SM 9 NA 10,000 2 1310
1000BASE-ELX SM 9 NA 70,000 2 1550
