APC Step-Down Transformer User Manual

5

Rack Installation

Rack Installation

Install the Rails

For details on support rail installation, refer to the instructions in the rail kit.

Install the Transformer

Attention: Install the transformer directly above the UPS.

Install the bezel and bracket components that correspond to your specific configuration (i.e. Smart-UPS

®

,

Smart-UPS RT

®

, Symmetra

®

).

Symmetra

configurations

Smart-UPS

configurations

Smart-UPS RT

configurations

Smart-UPS
configurations

Attention: The bezel which corresponds with Smart-UPS configurations must be installed at

the same time as the brackets.

Symmetra

configurations

Smart-UPS RT

configurations
