Introduction

Electrical Specifications

Attention:

Operation above the input voltage range may cause equipment damage.

Operation below the input voltage range may cause overload or automatic shutdown. When

connecting directly to a branch circuit, check that the line voltage is within specifications. When

connecting to the UPS, check that the line voltage into the UPS is within specifications before

transferring to bypass mode.

Note: In order for AP9626 models to output the full 5000 VA, the input must be hardwired to a 5500 VA source.

*For continuous operation below Vin = 205 Vac, the output load must be reduced to limit the maximum input
current to the amount specified above. Continuous operation above the maximum specified input current may
cause the unit to overheat and shut down. Please contact APC for additional information.

** Not available for AP9627.

Installation

With Line Cord

(AP9826 or AP9627)

With Hardwire

(AP9626 or AP9628)

Nominal Input Voltage

208 Vac

Nominal Output Voltage

120 Vac

Input Voltage Range

185-230 Vac*

Input Current Rating

24 A

26 A

Line Frequency

60 Hz

Efficiency

90-95%

Maximum Input Power

5000 VA

5500 VA

Maximum Output Power

4500 VA

5000 VA

Model

AP9626

AP9627

AP9628

Input Power

Distribution

3 ft cord with L6-30P or

hardwired

2 ft cord with L6-30P

Hardwire

Output Power

Distribution

(2) 15 A circuits with

(4) 5-20R and (2) 15 A circuits

with (2)5-20R

(4) 20 A circuits with

(4) L5-20R

Hardwire
