HDTV UpConverter 9
English
Introduction
: Product Features :
High Defi nition Input – We have published the capability to accepting standard
defi nition input and upconverting the video signal to HDTV resolutions. We are happy
to advise that the HDTV UpConverter can accept HDTV signals from terrestrial set
top box tuners, HD satellite receivers and HDTV Digital Cable boxes through any of
the three (3) Component video inputs. The UpConverter can receive signals at 480p,
720p or 1080i.
Product Specifi cations:
Specifi cations:
Front Panel:
• Power On/Standby
• Display showing input, display resolution, TV channel
• TV Tuning buttons
• Source and resolution select buttons
Inputs:
• 3 - RCA Video jacks
• 3 - S-VHS jacks
• 3 - Component video jacks (480i/480p, 1080i)
• 1 - 125 channel cable ready tuner
• 9 - R+L RCA Audio jacks
Outputs:
• 1 – HDTV Component jack
• 1 – R + L RCA jack
Video Input:
• Std. Defi nition 480 interlaced or progressive scan 480p, and HD sources of 720p and 1080i
Video Output:
• HDTV 480p, 720p or 1080i resolutions as well as additional output resolutions for fi xed pixel
display devices of 852 x 480p, 1024 x 1024p, 1280 x 768p, 1280 x 1024p
Power:
• Internal Switching Power Supply
• Input: 110-240 VAC
Requirements:
• HDTV Ready TV, Plasma, LCD or projector with HD Component Video Inputs (YPbPr)
• Analog Video source w/RCA, S-VHS or Component Video output or analog TV signal
