HDTV UpConverter 12
English
Introduction
REAR PANEL:
Rear Panel
1.) High Defi nition Component Video Outputs (YPbPr/YCbCr)
2.) Set of 3 High Defi nition Component (YPbPr) video inputs (480i – 1080i)
3.) Set of 3 S-Video (Y/C) inputs
4.) Set of 3 RCA video (Composite) input Jacks
5.) Analog Cable Ready 125 channel Tuner
6.) Right and Left Stereo audio inputs – matched to switch with corresponding video inputs.
7.) Right and Left Stereo audio outputs
8.) AC Power Receptacle
: Product Features :
