HDTV UpConverter 11
English
Introduction
VFD Display Window – The Vacuum Fluorescent Display provides information about the
current status of the HDTV UpConverter.
Channel Up/Down Buttons – Use these buttons when TV is the current video source to
change TV channels.
VFD Display
1.) TV Channel – displays the current channel you are viewing
2.) Current Output Resolution – indicates the current video resolution that is being
sent to your display device (480i, 480p, 720p, 1080i, etc.)
3.) Video Source – displays source descriptions (Comp YPbPr, S-Video, RCA Video or
TV Tuner) and either the source number (1-9) or the TV channel (1-125).
