Specifications:
1. Image Device : 1/3” CCD with 10 Bit A/D Digital Signal Processor.
2. Signal System: CCDLF NTSC, Standard image.
3. Total Effective Pixels: NTSC:537(H)*505(V).
4. Resolution: Greater than 250,000 pixels Greater than 420 TV Lines.
5. Power source : DC12V
6. Video Output:1.0Vp-p Composite( 75 ohm load).
7. Low Lux Sensitivity :0.2 Lux
8. S/N Ratio : More than 48db.
9. Current: 80mA
10. Operating Temperature: -13
o
F to 158
o
F (-25
o
C to 70
o
C)
11. Wide Angle View : Diagonal 150° (natural state lens declination 40
degrees)
12. Camera Outer Dimensions: 25mm(w) x 30mm(H) x 62mm(D)
