LG 50PV490 - Manual (Page 85)

85
ENG
ENGLISH
SPECIFICATIONS
RF module (BM-LDS201) specification (For PZ850 series)
For TV By using a 2.4 GHz bandwidth radio frequency(RF).
y y Output: 1 dBm or lower
y y Maximum Communication Distance: 10 m (30 ft) in an open space
y y Bandwidth: 2.4 GHz (2.4035 GHz - 2.4783 GHz)
y y Transfer Rate: 250 kbps
y y FCC ID of RF module inside TV
FCC ID: BEJLDS201
MODELS
50PZ850
(50PZ850-UA)
60PZ850
(60PZ850-UA)
Dimensions
(W x H x D)
With stand 1168.7 mm x 777.0 mm x 349.2 mm
(46.0 inch x 30.5 inch x 13.7 inch)
1387.1 mm x 920.5 mm x 395.6 mm
(54.6 inch x 36.2 inch x 15.5 inch)
Without stand 1168.7 mm x 712.2 mm x 52.5 mm
(46.0 inch x 28.0 inch x 2.0 inch)
1387.1 mm x 834.9 mm x 52.5 mm
(54.6 inch x 32.8 inch x 2.0 inch)
Weight With stand 30.1 kg (66.3 lbs) 42.0 kg (92.5 lbs)
Without stand 28.1 kg (61.9 lbs) 38.5 kg (84.8 lbs)
Current Value / Power consumption 3.7 A / 370 W 5.3 A / 530 W
Power requirement AC100 - 240 V ~ 50 / 60 Hz
