GENERAL FUNCTIONS AND CONTROLS
© American Audio ® - www.AmericanAudio.us - CDS-1™ Instruction Manual Page 8
A. TOP UNIT CONTROLS (FIGURE 3)
1. STOP - The stop button is used to stop CD
playback. Never open the transport door without
stopping playback first.
2. OPEN (Transport Tray Open) - This button is
used to open the disc transport tray door.
NOTE:
When a disc is loaded, the tray will not open
unless the unit is in pause or cue mode.
3. LIQUID CRYSTAL DISPLAY (LCD) - This
high quality LCD Indicates all the functions (play,
pause, etc...,), as they occur. This display is view-
able at several comfortable angles as described
on page 11. The LCD will be described in the
next section.
4. SGL/CTN - This button changes the play
mode between Single and Continuous. In single
mode the unit will play a single track and return
to cue mode. In continuous mode the unit con-
tinues to play track by track and returns to cue
mode after all tracks have played. This function
Figure 3
1
2
3
4
5
6
7 8 9 10 11 12 13
16
17
18
19
20
21
14 15
22
23
AC IN ~ 115V 230V
AUDIO OUT
R L DIGIT AL
OUTPUT
FADER
STAR
T
POWER
ON OFF
24 25 26 27 28 29
