EXTERNAL
EQ
UIPMENT
SETUP
18
EXTERNAL EQUIPMENT SETUP
Component Connection
DVD SETUP
HDMI Connection
Connect the video outputs (Y, P B , P R
) of the DVD to the
C CO OM MPPO ON NEEN NTT IIN N VVIID DEEO O1 1 jacks on the TV.
Match the jack colors (Y = green, P B = blue, and P R = red).
Connect the audio outputs of the DVD to the
C
CO OM MPPO ON NEEN NTT IIN N AAU UD DIIO O1 1 jacks on the TV.
1. How to connect
2. How to use
■ Turn on the DVD player, insert a DVD.
■ Select the C Coom mppoonneenntt 1 1 input source on the TV using
the IIN NPPU UTT button on the remote control.
■ If connected to C CO OM MPPO ON NEEN NTT IIN N 2 2 input, select the
C Coom mppoonneenntt 2 2 input source on the TV.
■ Refer to the DVD player's manual for operating instructions.
2
1
AUDIO
(RGB/DVI)
RGB(PC)
EMOTE
NTROL IN
HDM
2
1
O
COMPONENT IN
1
2
VIDEO AUDIO
Y L R P B P R
( ) ( )
( )
1 2
Connect the HDMI output of the DVD to the
H
HD DM MII//D DVVII IIN N1 1, 22, or H HD DM MII IIN N3 3 jack on the TV.
No separate audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■ Select the H HD DM MII1 1, H HD DM MII2 2, or H HD DM MII3 3 input source on
the TV using the IIN NPPU UTT button on the remote control.
■ Refer to the DVD player's manual for operating instructions.
2
1
OMPONENT IN HDMI/DVI IN
2
1
DEO
L P B P R R
AUDIO
HDMI-DVD OUTPUT
( ) ( )
( )
1
