PREP
AR
ATION
9
STAND INSTRUCTION
■ Image shown may differ from your TV.
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Assemble the TV as shown.
1
2
Fix the 4 bolts securely using the holes in the
back of the TV. 3
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage. 1
Loose the bolts from TV. 2
Detach the stand from TV. 3
42PG10/20/20C 50PG10/20/20C
/30/30C
60PG30/30C
After removing the stand, install the included
pprrootteeccttiioonn ccoovveerr over the hole for the stand.
Press the PPRRO
OTTEEC CTTIIO ON N C CO OVVEERR into the TV
until you hear it click.
Protection Cover
G G When assembling the desk type stand, check
whether the bolt is fully tightened. (If not tight-
ened fully, the product can tilt forward after the
product installation). If you tighten the bolt
with excessive force, the bolt can deviate from
abrasion of the tightening part of the bolt.
NOTE !
Only 42PG10/20/20C
Installation Detachment
