Spiders or small insects can build nests, webs and lay eggs
in the grills venturi tubes obstructing the flow of gas to the
burner. The backed-up gas can ignite behind the control
panel causing damage to the grill and even injury to the
operator. This is known as a “flashback”.
In order to prevent flashbacks, the burner(s) should be
removed from the grill and cleaned periodically, especially if
the grill has been stored for an extended period of time.
SPIDER ALERT!
Control Panel
Burner
Valve
Spider Webs or Nest
Inside Venturi Tube
Venturi Tube
Should you notice that your burner(s) are getting hard to light
or the flame is not as hot as it once was, Refer to the “How
to Clean your Burners” Section to remove any possible
obstructions.
CLEANING THE BURNERS
How to Clean the Burners:
1) Make sure the LP cylinder grill control knobs are turned
OFF; and the grill is completely cooled.
2) Carefully remove Cooking Grids and Flame Diffusers.
3) Remove the Control Knobs.
To reduce the risk of a fire beneath the grill:
· Inspect and clean burner/venturi tubes for insects and
insect nests.
· Be sure burners are re-installed properly before using
grill.
· Inspect burners periodically, if large cracks or holes
are found, replace the Burner.
4) Remove the three screws retaining the Control Panel.
Lift the Control Panel up and out. (FIG. 15A)
FIG. 15A
Control Panel
5) Remove the Rear Body Panel by removing the two screws
on both sides of the grill. (FIG. 15B)
FIG. 15B
Rear Body Panel
Remove two screws
6) Remove the screw connecting the crossover tube and
burner. (FIG. 15C)
7) Remove the two bolts and nuts securing the electrode to
the burner.
8) Remove bolts and nuts securing burner to Firewall .
6) Remove screw
and Burner
Crossover.
FIG. 15C
8) Remove Burner
Bolts and Nuts.
7) Remove Electrode Bolts and Nuts
