Local Terminal Configuration
Using a Local Terminal
38
Figure 2-11: Modify/View Serial Port Settings Menu
2. Select each field requiring configuration (one at a time) by selecting its
corresponding number as shown in Figure 2-11 and then entering the values
that are appropriate for your modem’s serial port.
Serial port IP address Press 3 and then enter the serial port IP address for the
probe. The default Serial Port IP Address is 0.0.0.0 .
Serial port Press 4 and then enter the serial port subnet mask for
subnet mask the probe (optional). It is recommended that you do not
change the serial port subnet mask unless there is a
conflict. The default Serial Port Subnet Mask is
255.255.255.192.
Modify/View Interface Values Menu - Firmware Rev
Interface Type Serial
1. Port 1.2/Serial
2. Port Type Not Applicable
3. Serial port IP address 0.0.0.0
4. Serial port subnet mask 255.255.252.192
5. Serial port speed 9600
6. Serial port mode Direct
7. Serial port hardware flow control On
8. Modem Init String ^s^M^d1^sATE0Q0V1X4 S0=1...
9. Modem Hangup String ^d2^s+++^d2^sATH0^M^d2
10. Modem Connect Responses /CONNECT/300/CONNECT/1200/...
11. Modem No-Connect Responses /NO CARRIER/BUSY/NO DIALT...
S. Save Changes and Exit
0. Cancel Changes and Exit
