XM4-Truck Satellite Radio Antenna
5
Packaging Contents
The following items are contained within
the packaging for the XM Truck Antenna:
(1) Antenna Assembly
(1) Mirror Mount Clamp A
(1) Mirror Mount Clamp B
(4) M6XP1.0 Hex Screws
(4) M6 Washers
(4) M6 Lock Washers
(4) M6XP1.0 Hex Nuts
(1) 3/4 Ext. Tooth Lock Washer
(1) 3/4 -16 Hex Nut
(1) U-Bracket Assembly
(1) Air Dam Shield Clamp D
(1) 3/8-16 Hex Nut
(1) 3/8 Split Lock Washer
(1) 21 foot RG-174/U
Low-Loss Coax Cable with
R/A SMB Connector
Recommended Tools Required
(Note: Not all Tools listed are needed-see Text)
Appropriate Open-End Wrenches:
• 3/4”
• 3/8”
• 10mm
• 9/16”
• 5/16”
• Torque Wrench, 12 ft-lbs. (144 in-lbs.)
Capability with appropriate adapters:
10mm, 1/2”, 9/16”, 1-1/8” hex sockets.
Figure 2. Mirror Mounting
Figure 3. Air Dam Shield
or Flap Mounting
A
B
