1-6 Chapter 1: Product introduction
1.5 Motherboard overview
1.5.1 Motherboard layout
1 2 2 3
CLRTC1
Normal Clear CMOS
(Default)
USBPW34
USBPW12
+5V
(Default)
+5VSB
2 3 2 1
USBPW56
USBPW78
+5V
(Default)
+5VSB
2 3 2 1
(Default)
+5V +5VSB
KBPWR
2 3 1 2
PANEL
* Requires an ATX power supply.
PLED-
PWR
+5V Speaker
PLED
Ground
RESET
Ground Reset
Ground Ground PLED+
IDE_LED- IDE_LED+
IDE_LED
SPEAKER
PWRSW
24.5cm (9.6in)
PCI1
P4S800-MX SE
CR2032 3V
Lithium Cell
CMOS Power
CD AUX
Super
I/O
4Mb BIOS
PS/2KBMS
T: Mouse
B: Keyboard
Below:Mic In
Center:Line Out
Top:Line In
AGP
CPU_FAN1
FP_AUDIO
RTL8201CL
GAME
CLRTC1
FLOPPY
PRI_IDE SEC_IDE
A
TXPWR
DDR DIMM1 (64 bit,184-pin module) DDR DIMM2 (64 bit,184-pin module)
USB12
USB56
24.5cm (9.6in) USBPW12
USBPW34
USBPW56
P
ARALLEL
PORT
COM1
VGA
PCI2
PCI3
SPDIF
SiS
661FX
North Bridge
SiS
964
Chipset
SB_PWR
KBPWR
Socket 478
ATX12V
USB34
USBPW78
ALC655
USB78 PANEL
SATA2
SATA1
TOP
RJ-45
