PAGE 37 Community XLT / XLTE Series Owner’s Manual
11.2 MONITOR SPEAKERS AND SUBWOOFERS 1
Model: 41 48 51 55
System Type 2-Way Monitor wedge
and upright PA
2-Way Monitor
wedge
Trapezoidal
Subwoofer
Trapezoidal
Subwoofer
Frequency Response 70 Hz - 18 kHz 50 Hz - 18 kHz 40 Hz - 250 Hz 40 Hz - 150 Hz
Sensitivity (1W / 1m SPL) 97 dB 98 dB 98 dB 98 dB
Max. Power (RMS / Program)
Passive Mode
Biamp Mode LF
HF
200 W / 500 W
200 W / 500 W
50 W / 125 W
200 W / 500 W
200 W / 500 W
50 W / 125 W
125 W / 300 W
N/A
N/A
300 W / 750 W
N/A
N/A
Impedance
Passive Mode
Biamp Mode LF
HF
8 Ohms (min 5.2)
8 Ohms (min 5.2)
8 Ohms
8 Ohms (min 5.5)
8 Ohms (min 5.5)
8 Ohms
8 Ohms (min 7.8)
N/A
N/A
4 Ohms (min 4.4)
N/A
N/A
Nominal Coverage H x V 90° x 40° 2 90° x 40° Omni Omni
Crossover: Type
Frequency
12 dB/octave
2 kHz
12 dB/octave
2 kHz
High-pass output
150 Hz
High-pass output
150 Hz
Passive/Biamp Switch Yes Yes N/A N/A
HF Level Switch +4 dB / Flat +4 dB / Flat N/A N/A
PowerSense™ DDP
3
With Front / Rear Indication
Yes Yes Yes Yes
Drivers HF
4
LF
1" / 25 mm titanium
12" / 305 mm
1" / 25 mm titanium
15" / 381 mm
N/A
1 x 15" / 381 mm
N/A
2 x 15" / 381 mm
Input Connectors
Neutrik NL4MP (Passive/Biamp)
1/4” Jack (Passive only)
(2) In parallel
(2) In parallel (2) In parallel
(2) In parallel (2) In parallel
(2) In parallel (2) In parallel
(2) In parallel
XLT Enclosure Material
XLT
XLTE
N/A
13-ply Baltic birch
Oriented strand board
13-ply Baltic birch
Oriented strand board
13-ply Baltic birch
Oriented strand board
13-ply Baltic birch
Mounting Points
XLT (5/16-18 T-nuts)
XLTE(3/8-16 rig points)
N/A
Nono
Sides
Sides (5/16-18 T-nuts)
Sides/top/bottom
3 top, 3 bottom
Sides/top/bottom
3 top, 3 bottom
Stand / Pole Socket 1-3/8” / 35 mm
diameter
Attachment points
for external socket 1-3/8” / 35 mm
diameter
None
All-Steel Handles One on end One on each side One on each side One on each side
XLT Corner Protectors N/A Yes Yes Yes
XLTE Rubber Feet Yes Yes Yes Yes
Enclosure Finishes
XLT
XLTE
N/A
Black Paint 1
Black Carpet
Black Paint 1
Black Carpet
Black Paint
Black Carpet
Black Paint
Grille Material
Finish
16 Gauge perf steel 1
Black paint 1
16 Gauge perf steel 1
Black paint 1
16 Gauge perf steel
Black paint
16 Gauge perf steel
Black paint
Dimensions 5 Height
Width (front)
Width (rear)
Depth
14.9" / 379 mm 6
24.4" / 620 mm 6
24.4" / 620 mm 6
15.6" / 395 mm 6
19.3" / 483 mm 6
20.3" / 515 mm 6
20.3" / 515 mm 6
31.5" / 800 mm 6
27" / 686 mm
20" / 507 mm
20" / 507 mm
18.4" / 468 mm
41.9" / 1065 mm
20.3" / 515 mm
13.7" / 337 mm
18.2" / 457 mm
Pitch between sides 30 or 45 degrees 7 30 degrees 7 0 degrees 22 degrees
Weight XLT
XLTE
52 lb. / 23.6 kg
49.5 lb. / 22.5 kg
62.5 lb. / 28.4 kg
60 lb. / 27.2 kg
59 lb. / 26.8 kg
66.5 lb. / 30.2 kg
89 lb. / 40.4 kg
89 lb. / 40.4 kg
1 See APPENDIX for additional specifications for XLT41E and XLT48E.
2 Horn can be rotated 90 degrees to reverse horizontal and vertical coverage pattern.
3 DDP = Dynamic Driver Protection.
4 Driver has as 2” diameter diaphragm and 1” exit.
5 Dimensions are for XLT models including corners. XLTE dimensions will vary up to approximately +/- 0.5 in. (+/- 13 mm)
from the listed dimensions.
6 Dimensions are for normal operating position as a floor monitor.
7 For monitors: pitch = Slant angle of front from horizontal in normal operating position.
