APM CO., LTD
ALP-9287
Output Power (HIGH-POWER) 11g: 22dBm (Typical)±1
11b: 26dBm (Typical)±1
Data Rate 11g: 54, 48, 36, 24, 18, 12, 9 and 6Mbps with auto-rate fall back
11b: 11, 5.5, 2, and 1Mbps with auto-rate fall back
Sensitivity 54Mbps: -68dBm
11Mbps: -80dBm
Working Mode Ad-Hoc or Infrastructure
Throughput 22Mbps@54Mbps; 5.5Mbps@11Mbps
Host Interface A-Type USB 2.0 connector
Operating Temperature 0~55 ambient temperature℃
Storage Temperature -20~70℃ ambient temperature
Power Consumption Continuous transmission mode: 290mA at 5VDC (Max.)
Continuous reception mode: 240mA at 5VDC (Max.)
Operating & Storage Humidity 90% maximum (non-condensing)
Operating System Support
Windows® 98SE/ME/2000/XP/VISTA, Mac® 10.4
Approval FCC Part 15
CE
