APM CO., LTD
AAWAP608H
200mW Long-Range
802.11g Turbo mode 72Mbps Accesss Point
Passive PoE Support
Complies with IEEE 802.11b/g wireless standards
High speed transfer data rate up to 54Mbps
Supports turbo mode for 72Mbps data transfer
Supports wireless data encryption with 64/128-bit WEP,
WPA (TKIP with IEEE 802.1x), WPA2 and AES functions.
Supports one switch for selecting AP client mode or AP mode
Supports Ad Hoc mode, Infrastructure mode,
AP Bridge mode, AP Bridge WDS mode and Repeater mode
Provides one 802.11b/g wireless Reverse SMA detachable antenna
Supports authentication for wireless connectivity based on ESSID
Provides MAC access control and hidden SSID function
WDS supported with WEP, TKIP and AES encryption
Channel : USA 11, Europe 13, Japan 14
Supports DHCP server
Supports firmware upgrade function via Web
Flash : 2MB, SDRAM : 8MB
Model Name
AAWAP608H
Product Name
WLAN AP
Standard
802.11b/g(Wireless), 802.3(10BaseT), 802.3u(100BaseT)
Data Transfer Rate
54Mbps(Wireless), 100Mbps(Ethernet)
Modulation Method
CCK (802.11b), OFDM (802.11g)
Frequency Band
2.4GHz – 2.497GHz ISM Band, DSSS
RF Output Power
24~23 dBm
Receiver Sensitivity
802.11b -80 dBm@8%, 802.11g -68 dBm@5%
Operation Range
30m ~ 100m
Antenna
External Antenna
LED
Power, LAN, Wireless
Security
64 bit/128 bit WEP, WPA, WPA2,
Power Consumption
12V DC Power Adapter
Operating Temperature
0 – 50° C ambient temperature
Storage Temperature
-20 ~ 70°C ambient temperature
Humidity
5 to 90% maximum (non-condensing)
Dimension
111*79*30 mm
Spectifications
Features
22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: +886 2 89431966 Fax: +886 2 89434944
