APM CO., LTD

AAIP-W406N

Compatible with IEEE 802.11n, 802.11b/g wireless standards.
Provides three 802.11n/b/g wireless Reverse SMA detachable antennas.(Standard 2dB)
High speed transfer data rate up to 300Mbps
Supports wireless data encryption with 64/128-bit WEP, WPA and WPA2
Supports authentication for wireless connectivity based on ESSID
Supports Multiple BSSID.
Provides MAC access control and hidden SSID function
WDS supported with WEP, TKIP and AES encryption
Channel : USA 11, Europe 13
Supports NAT IP Sharing
Supports WAN connection type-Static IP, PPPoE, PPTP, & DHCP client
SPI Anti-DoS Firewall; Virtual DMZ; DNS relay; UPnP
Provides DHCP server and client
Supports ALG for FTP, NetMeeting, DDNS (DynDNS, TZO)
Supports QoS:WMM
Supports firmware upgrade function via Web
Supports system log
Compliant with FCC Part 15.247 for US, ETS 300 328 for Europe
Certifications : FCC Class B, CE Mark, VCCI Class B

Standards

IEEE 802.11n IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u

Interface

LAN: 4 port 10/100Mbps Ethernet, RJ-45
WAN: One RJS45 port
3* 802.11n/b/g wireless reverse SMA detachable 2dBi antenna

Security

64/128-bit WEP, WPA, WPA2
2.4GHz~2.4835GHz

Receiver Sensitivity

11Mbps-91dBm, 54Mbps-78dbm, 300mbps -69dbm

Channel

USA 11, Europe 13

Transmit Power

11Mbps 18dbm, 54Mbps 16dbm, 11n 20MHz and 11n 40MHz 16dbm

Range Coverage

Indoor 35~100 meters Outdoor 100~300meters.

LED Display

1*Power, 1*WAN, 4*LAN, 1*Wireless

Environmental

Temperature: 0° ~ 40°C (32° ~ 104°F)
Humidity: 10 ~ 95% RH non-condensing

Dimension

150x80x30mm

Certification

FCC Class B, CE Mark

Power

External: DC 12V, 1A

Frequency band

Spectifications

Features

IEEE802.11n Wireless Router

22F-6, No.180, Jingping Rd, Jhonghe City, Taipei County 23581, Taiwan, R.O.C.

www.apm.com.tw [email protected] Tel: +886 2 89431966 Fax: +886 2 89434944
