A S U S M 2 N P V - M X A S U S M 2 N P V - M X A S U S M 2 N P V - M X A S U S M 2 N P V - M X A S U S M 2 N P V - M X 1 - 2 3 1 - 2 3 1 - 2 3 1 - 2 3 1 - 2 3
3 . 3 . 3 . 3 . 3 . K e y b o a r d p o w e r ( 3 - p i n K B P W R ) K e y b o a r d p o w e r ( 3 - p i n K B P W R ) K e y b o a r d p o w e r ( 3 - p i n K B P W R ) K e y b o a r d p o w e r ( 3 - p i n K B P W R ) K e y b o a r d p o w e r ( 3 - p i n K B P W R )
This jumper allows you to enable or disable the keyboard wake-up
feature. Set this jumper to pins 2-3 (+5VSB) to wake up the
computer when you press a key on the keyboard (the default is the
Space Bar). This feature requires an ATX power supply that can supply
at least 500 mA on the +5VSB lead, and a corresponding setting in
the BIOS.
M2NPV-MX
®
M2NPV-MX Keyboard power setting
KBPWR
1
2 2
3
+5V
(Default)
+5VSB
