PRODUCT DESCRIPTION
GENERAL OVERVIEW
210 mm
180/280 mm
145 mm
1
2
3
4
1
Induction cooking zone
2
Double induction cooking zone
3
Control panel
4
Induction cooking zone
CONTROL PANEL LAYOUT
1
2
4
5
3
6
8
9
10
7
Use the sensor fields to operate the appliance. The displays, indicators and
sounds tell which functions operate.
Sensor field
Function
1
To activate and deactivate the appliance.
2
To lock / unlock the control panel.
3
/
To increase or decrease the heat setting.
4
Timer indicators of cooking
zone.
To show for which zone you set the time.
5
The timer display.
To show the time in minutes.
6
A heat setting display.
To show the heat setting.
7
To activate the Power function.
8
To select a cooking zone.
9
/
To increase or decrease the time.
ENGLISH
5
